Pigment ljubičasta 23-Corimax Violet RLS

Pigment violet 23 is an organic compound that is a commercial pigment. It is member of the dioxazine family of heterocyclic compounds, but derived from carbazoles. It is prepared by condensation of chloranil and 3-amino-N-ethylcarbazole. It has a centrosymmetric angular structure. For many years, the structure was assigned, incorrectly, as having a "linear structure" (EC no. 228-767-9, CAS RN 6358-30-1) which differ in terms of the carbazole ring fusion.

Pigment violet 23 is prepared by condensation of an aniline with chloranil.[From Wiki]

Tehnički parametri pigmentne ljubičice 23

Indeks boja br.Pigmentna ljubičica 23
Ime proizvodaCorimax Violet RLS
Kategorija proizvodaOrganski pigment
Brzina svjetlosti (premaz)7
Otpornost na toplinu (premaz)200
Brzina svjetlosti (plastična)7
Otpornost na toplinu (plastika)250
Boja
Pigment-ljubičasta-23-boji
Distribucija nijansipv

Zeyachem is a global supplier of Dioxazine Violet pigments that provide a bluish violet shade, a color not obtainable by other pigments.

The extremely high color strength of Pigment violet 23 makes it a suitable pigment as a shading component. PV23 also exhibits excellent heat fastness and light fastness properties, making it suitable for inks and many paints and coatings applications.

Corimax Violet RLS is a reddish blue shade Dioxazine Violet (PV23) pigment with very high color strength and excellent overall fastness properties, suitable for inks, paints and coatings, including industrial coatings, powder coatings and automotive coatings.

Značajke:

low viscosity, high gloss, high color strength. Pigment Violet 23 is a transparent purple violet pigment with high saturation and tinting strength.

C.I.Pigment Violet 23 show good tinting strength in flexible PVC while poor resistance to immigration.

P.V.23 heat resistance above 230℃ in polyolefins, when used in transparent PS, temperature shall below 220℃, above this PV 23 shall decompose. When worked in polyester, it is 280℃ stable in 5 hours, while concentration shall above 0.05%.

The pigment is easy to use and requires no rinsing. To ensure maximum color intensity and proper adhesion to the pulp, a retention agent must be added to the pulp before the pigment is applied. Our pigments are supplied by volume sizes. The actual weight varies, depending upon the density of the pigment.

primjena:

Preporučuje se za automobilske boje, arhitektonske premaze, zavojnice, industrijske boje, praškaste premaze, tiskarske paste, PVC, guma, PS, PP, PE, PU, ofsetne boje, masti na vodenoj bazi, otapala, UV mastila.

Pigment Violet 23 (PV 23) has now been around for more than 55 years. Its beginnings go back to 1928, when a patent was filed for the pigment after researchers at the Hoechst company in Germany first undertook the multistage synthesis based on carbazole, an ingredient of coaltar, and chloranile. Until the end of World War II the pigment was only used to process diamine light blue, a direct dyestuff for cotton.

With the invention of reactive dyes, which considerably simplified the dyeing and printing process for cellulose fibers, this application lost its importance. A new and promising use for PV 23 was quickly found due to the pigment’s ability to produce unique colors.

PV 23 has been used as a pigment since 1953. PV 23 belongs to the group of high-performance polycyclic pigments (HPP’s) that are used whenever the requirements for a colorant are particularly high. These include high light fastness and weather fastness, fastness to solvents, and heat stability. In addition, PV 23 stands out by its high coloring power. Under the electron microscope, the crude violet shows a highly granular crystalline form, whereas the pigment particles are miniscule.
-------------------------------------------------- ---------------

Povezane informacije

Fizička i kemijska svojstva:
Hue ili light: plavo ljubičasta
Relativna gustoća: 1,40-1,60
Nasutna gustoća / (lb / gal): 11,7-13,3
Talište / ℃: 430-455
Prosječna veličina čestica / μm: 0,04-0,07
Oblik čestica: kubični / šipka
Specifična površina / (m2 / g): 45-102
pH vrijednost / (10% kaša): 6.2

Upotreba proizvoda:Pigmentna ljubičica 23 uglavnom se koristi za bojanje premaza, mastila, gume i plastike, a također i za bojanje sintetičkih vlakana
Postoje 124 vrste marke komercijalne formulacije pigmenta. Karbazoazin je vrsta plave ljubičice s jakom i neobičnom primjenom, a specifična površina monolitne ljubičice RN je 74m2 / g. Široko se koristi u raznim područjima kao što su premazivanje, ispis s tintom, tiskanje plastike i tkanina i bojenje. Ima dobru postojanost lakiranja prilikom bojenja. Može se koristiti za sušenje na zraku, automobilsku boju OEM i boju za pečenje, posebno za lateks boje s CuPc tonikom i jakim svjetlosnim tonom. Može se koristiti za plastično bojanje, s otpornošću na toplinu od 280 ℃ u poliolefinu i visokim zadržavanjem boja (samo 0,07% koncentracije pigmenta potrebno je za HDPE s 1 / 3SD); može se koristiti i za bojanje poliestera i PE.

Princip sinteze: Karbazol se koristi kao sirovina, a N-etilacija se vrši pod normalnim tlakom u prisutnosti katalizatora faze inverzije, a reakcija nitracije i redukcija provode se za sintezu 2-amino-N-etilkarbazola; 3,5,6-tetrakloroparakinon (kloranil) podvrgnut je reakcijama kondenzacije i zatvaranja prstena, filtriran, ispran vodom i osušen da se dobije sirova karbazola ljubičica; napokon, opći tretman pigmentacije grickanjem ili gnječenjem kako bi se dobila CI pigmentna ljubičica 23.

nadimci:Pigment Violet RL; 51319; C.I. Pigment Violet 23; 8,18-Dichloro-5,15-diethyl-5,15-dihydrodiindolo(3,2-b:3',2'-m)tri- phenodioxazine; CI 51319; Diindolo(3,2-b:3',2'-m-)triphenodioxazine, 8,18-dichloro-5,15-diethyl-5,15-dihydro-; Carbazole Dioxazine Violet; Carbazole Violet; Chromofine Violet RE; Cyanadur Violet; Dioxazine Violet; Dioxazine purple; EB Violet 4B7906; EMC Violet RL 10; Fastogen Super Violet RN; Fastogen Super Violet RN-S; Fastogen Super Violet RTS; Fastogen Super Violet RVS; Helio Fast Violet BN; Heliofast Red Violet EE; Heliogen Violet; Heliogen Violet R Toner; Hostaperm Violet RL; Hostaperm Violet RL Special; Hostaperm Violet RL Special 14-4007; Lake Fast Violet RL; Lake Fast Violet RLB; Lionogen Violet R 6100; Lionogen Violet RL; Lionol Violet HR; Monolite Fast Violet R; PV Fast Violet BL; PV Fast Violet RL-SPE; Paliogen Violet 5890; Paliogen Violet L 5890; Permanent Violet; Permanent Violet R; Sandorin Violet BL; Sanyo Permanent Violet BL-D 422; Sumikacoat Fast Violet RSB; Sumitone Fast Violet RL; Sumitone Fast Violet RL 4R; Sumitone Fast Violet RLS; Symuler Fast Violet BBL; Symuler Fast Violet BBLN; Unisperse Violet B-E; Vynamon Violet 2B; 8,18-Dichloro-5,15-diethyl-5,15-dihydrodiindolo(3,2-b:3',2'-m)triphenodioxazine; Diindolo(3,2-b:3',2'-m)triphenodioxazine, 8,18-dichloro-5,15-diethyl-5,15-dihydro-; 8,18-dichloro-5,15-diethyl-5,15-dihydrocarbazolo[3',2':5,6][1,4]oxazino[2,3-b]indolo[2,3-i] phenoxazine

Molekularna struktura:Pigment-ljubičasta-23 molekularne strukture
